1/4" CNC-Cut Aluminum. 100% Bolt-On Protection. Made in Colorado, USA.
Armor Built for the 3rd-Gen ColoradoThe 3rd-gen Colorado's engine, steering rack, and front differential all sit low and exposed. One poorly placed rock strike shouldn't end your weekend. The Juggernaut USA Engine Skid Plate is engineered to shield your most vulnerable components from rocks, ruts, and debris.
Crafted in our Wheat Ridge, Colorado shop, this plate is CNC plasma-cut and press-brake formed from premium 1/4-inch 5052-H32 aluminum. It offers the perfect balance of extreme durability and lightweight performance, ensuring your ZR2 or Z71 stays trail-ready without the weight penalty of traditional steel.
The Juggernaut AdvantageThe Pain: A cracked oil pan or bent steering rack means a massive tow bill and a repair cost that is 5x the price of this plate. Most steel plates also rust the moment they get scratched.
The Solution: Our 1/4" aluminum plate is thicker than standard 3/16" steel, provides superior bend resistance, and never rusts—even after heavy trail abuse.
Key Features: Heavy Duty Underbody Armor
Thicker than common 3/16" steel kits. This aluminum takes a massive hit before it stays bent, providing elite protection.
No drilling, cutting, or welding required. Uses factory mounting points for a true 1-2 hour DIY installation.
Unlike steel, aluminum won't rust when the powder coat chips. Ideal for trucks exposed to road salt or water crossings.
Total protection for the engine oil pan, steering rack, and front differential from a single, robust plate.
At only 30 lbs, it’s half the weight of steel. Keep your payload available for gear, not just heavy armor.
We don't skimp on the details. Every kit includes high-strength Grade 8 hardware to ensure the plate stays put.
Finished in a durable black powder coat for added abrasion resistance and a clean, integrated look.
We stand by our work. Juggernaut USA products are backed by a Lifetime Warranty for peace of mind on the trail.
Aluminum vs. Steel: Why 1/4" WinsResistance to permanent bending scales with the square of plate thickness. This means our 1/4″ 5052-H32 aluminum can take a harder hit before it deforms compared to the 3/16″ steel most competitors use. While steel has a harder surface for rock "sliding," aluminum wins for 90% of owners by being lighter, more resilient to bending, and completely rust-proof.
30 lbs Total Weight 1/4" Plate Thickness USA Made in Colorado Grade 8 Hardware Included
"Living in Denver, I’m in the mountains every weekend. The factory plastic/thin guards didn't cut it. I opted for the Juggernaut aluminum plate because I didn't want the extra weight of steel killing my gas mileage or causing rust issues with all the winter road salt. The install took me an hour in my driveway with basic tools. It's solid as a rock."
- Mark S., Colorado ZR2 Owner Fitment & Lift WarningCheck Your Lift: This skid plate will NOT fit vehicles with a 4" or larger lift kit, as aftermarket drop brackets and crossmembers interfere with the factory mounting points.
| Feature | Juggernaut 1/4" Aluminum | Typical 3/16" Steel |
|---|---|---|
| Bend Resistance | ✓ Higher (Thicker Plate) | ✗ Baseline |
| Weight | ✓ ~30 lbs (Easier on Payload) | ✗ ~60+ lbs (Heavier) |
| Corrosion | ✓ Won't Rust | ✗ Rusts where powder coat chips |
| Surface Hardness | ✗ Softer (Can gouge on granite) | ✓ Harder (Slides better on rocks) |
| Installation | ✓ True Bolt-On | Often heavier/requires 2 people |
Specifically designed for the 3rd Generation Colorado. Fits all cab and bed configurations:
2023–current Chevy Colorado 4x4 (2.7L Turbo) 2023–current Chevy Colorado 4x2 (2.7L Turbo) 2023–current Chevy Colorado ZR2 4x4 (2.7L Turbo)Note: Does not fit the 2023+ GMC Canyon. Ships next business day with free shipping to the lower 48 states.
No. All Juggernaut USA skid plates are engineered for true bolt-on installation. No drilling, cutting, or welding is required to secure this to your 2023+ Colorado.
Currently, this specific SKU is designed for the Chevrolet Colorado and will not fit the 2023+ GMC Canyon due to differences in lower fascia and mounting configurations.
That is the beauty of aluminum! If you scratch the black powder coat on a rock, the underlying aluminum will not rust. Steel plates require immediate touch-up paint to prevent corrosion, but our 1/4" aluminum remains structurally sound and rust-free forever.
The plate is designed to cover the oil pan for maximum protection. While it may need to be lowered for some service procedures, the bolt-on design with included Grade 8 hardware makes removal and reinstallation quick and simple during routine maintenance.
