Your Oil Pan's First Line of DefenseYour oil pan is the first thing a rock finds. The front underbody of a 2020+ Silverado HD leaves the engine oil pan and everything around it exposed to whatever the road or trail throws up. This 1/4" aluminum engine skid plate takes those hits so your oil pan doesn't — because a punctured pan strands a $70K truck, and this plate costs less than the tow.
Aluminum can't rust the way steel plates do — every scratch on steel armor is where corrosion starts, especially with road salt. Ours is 1/4" 5052 aluminum, powder-coated black, CNC plasma-cut and press-brake formed in our Wheat Ridge, Colorado shop.
Why Choose Juggernaut Protection?The Pain: A stock Silverado HD leaves the engine oil pan hanging low and unprotected — one rock strike can mean a punctured pan, a tow, and an engine out of commission.
The Juggernaut Solution: A full 1/4" aluminum shield that bolts to your factory mounting points — no drilling, no cutting — and costs less than the tow it prevents.
Key Features: Engine Skid Plate
Bolts on using your Silverado HD's factory mounting points. No holes, no cutting, no modifications to your truck.
Do routine oil changes without pulling the skid plate — the cutout gives you direct access to the drain plug.
Full quarter-inch aircraft-grade aluminum plate — lighter than steel armor and it won't rust, even with a scratch through the coating.
A tough black powder coat resists abrasion from rocks, gravel, and road debris.
Every bolt and bracket needed for installation ships in the box — no trip to the hardware store.
Designed, cut, and finished start-to-finish in our Wheat Ridge, Colorado shop from US-sourced aluminum.
One plate design covers both the gas and 6.6L Duramax diesel Silverado 2500HD/3500HD.
Covered against manufacturing defects in materials and workmanship for as long as you own it.
Over-Engineered in ColoradoWe don't cut corners. This plate is cut from full 1/4" 5052-H32 aluminum, CNC plasma-cut and press-brake formed, then finished in a durable black powder coat. It ships ready to bolt directly to your Silverado HD's factory mounting points.
25 lbs Plate Weight 1/4" Aluminum Thickness 5052-H32 Aluminum Grade Lifetime Warranty
Important Fitment Note
Check Your Lift Height: This plate will not fit vehicles with a 4"+ lift — aftermarket drop brackets and crossmembers interfere with the factory mounting points it uses.
*Repair and towing costs are general estimates and vary by shop, region, and vehicle condition.
| What Matters Underbody | Our 1/4" 5052-H32 Aluminum | Typical 3/16" Steel |
|---|---|---|
| Resistance to Bending | ✓ Higher — bend resistance rises with the square of thickness | ✗ Baseline |
| Weight | ✓ About half — easier on payload | ✗ Heavier |
| Corrosion | ✓ Won't rust | ✗ Rusts where the coating chips |
| Surface Hardness (drag over rock) | Softer — can gouge on granite | ✓ Harder — steel's real edge |
| Hardware | ✓ Included | Often Sold Separately |
| Origin | ✓ Made in USA (Colorado) | Imported |
Designed specifically for the Silverado HD's factory mounting points. Fits the following:
2020-current Chevrolet Silverado 2500HD — Gas & 6.6L Duramax Diesel 2020-current Chevrolet Silverado 3500HD — Gas & 6.6L Duramax DieselWill not fit vehicles with a 4"+ lift — aftermarket drop brackets and crossmembers interfere with factory mounting points.
CA Residents: ⚠️ WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Every plate is engineered for a specific year, make, and configuration, and we stand behind that fitment. If the part you receive doesn't fit the vehicle it was ordered for, we cover return shipping and send the correct part at no additional cost.
Minimal — the plate contours to the frame and tucks up against the underbody so it slides over obstacles rather than hangs low.
No — under the Magnuson-Moss Warranty Act, a bolt-on aftermarket part can't void your factory warranty on its own.
Yes — the plate includes an oil-drain access cutout so you can do routine oil changes without removing it.
This plate fits trucks with factory suspension or small leveling kits. It will not fit vehicles with a 4"+ lift, since aftermarket drop brackets and crossmembers interfere with the factory mounting points it uses.
